Braytron 24W SURFACE ROUND White 6500K LED Panel

Braytron 105045 - 24W SURFACE ROUND WHT 6500K LED PANEL-BRY BRYBP03-62430

General Characteristics

• Model No: BP03-62430
• Main Family: Indoor Lighting
• Sub Family: LED Small Panel
• Type: Surface Frame
• Body Color: White
• Lamp Shape: Non-Directional
• Dimmable: Not-Dimmable
• Light Source: LED
• Class: Class II
• IP: IP40

Product Characteristics

• Wattage: 24 w
• Color Temperature: 6500K
• Quse Lumen: 2400 lm
• Color Rendering Index (CRI): >80
• Energy Efficiency Level: F
• Beam Angle: 120° Degrees
• Color Category: Warm White

Electrical Characteristics

• Lifetime: 20000 h
• Voltage: 220-240V
• Power Factor: >0,5
• Material: PC
• Working Temperature: -20 C+40 C
• Frequency: 50-60 Hz

Dimensions & Weight

• Diameter: 300 mm
• P. Height: 33 mm
• Weight: 590 gr
