Afriso Thermometer 0-120° Achter 1/2" - Ø63mm - L= 40mm 63801
Afriso Thermometer 0-120° Achter 1/2" - Ø63 mm - L= 40 mm 63801
- Ranges:-20/+60, 0/60, 0/120, 0/160 °C
- Brass thermowell
- Stem brass or aluminium
Application
- Heating, plumbing
| Technical Data | |
| Nominal size 63 | Range °C 0/120 |
| Measuring element Bimetal helix | Application area Full scale value |
| Accuracy class 2 (EN 13190) | Operating pressure at thermowell Max. 6 bar |
| Standard Design | |
| Connection Stem:Brass or aluminium, ∅ 9 mm Thermowell: G½B, brass or aluminium, ∅ 9 mm (removable (with locking screw for 160 °C and higher)) | Pointer Plastic, black |
| Mounting position Centre back | Housing Sheet steel, galvanised |
| Dial Up to 120 °C: Plastic, white | Push on bezel Sheet steel, nickel-plated |
| Window Plastic | |
